HW-T4-44F/50F 4-head desktop pick and place machine with 50 feeder positions for small batch PCB assembly
Desktop 4 Heads Easy Setup

HW-T4-44F/50F Desktop Placer

Full-automatic small desktop placer with 4 high-precision placement heads, speed 5000-8000 Pcs/h, ideal for small batch production and prototyping.

Request Quote

Best For

  • R&D labs and prototyping teams
  • Small batch PCB assembly (high-mix, low-volume)
  • Startups and small electronics workshops
  • LED module sample and small batch production
  • Workshops with limited floor space
  • Frequent job changeovers (quick setup)

Not Ideal For

  • Very large PCB panels (over 350×260mm)
  • High-speed mass production (over 8,000 CPH needed)
  • Complex BOMs requiring 80+ feeder positions
  • 24/7 continuous high-volume production

Not sure whether this model fits your BOM? Read: How Many Feeders Do You Really Need for SMT Production? — understand feeder capacity, BOM complexity, and changeover planning before you decide.

Comparing models? See our full guide: How to Choose a Compact Pick and Place Machine — a 10-step framework covering PCB size, component range, feeder capacity, and more.

Key Features

  • 4 high-precision placement heads, simultaneous recognition of same-side components
  • Intel high-performance processor industrial motherboard
  • Electric rail adjustment, convenient for quick changeover
  • 50/44 electronic feeder positions (8mm tape to 3 inch IC tray)
  • Repeat placement precision: 0.02mm
  • AC servo motor drive, high-performance DSP control

Specifications

Model HW-T4-44F/50F
Placement Heads 4 high-precision placement heads
Placement Speed 5000-8000 Pcs/h
Feeder Positions 50/44 positions (8mm tape to 3 inch IC tray)
Repeat Placement Precision 0.02mm
Positioning Accuracy 0.01mm
PCB Placement Area 350 x 190mm / 350 x 260mm
XY Stroke Range 629mm x 679mm
Drive Motor AC servo motor
Vision System 1x MARK camera, 1 high-speed recognition camera, 1 high-precision vision camera
Operating System Windows-based, self-developed SMT intelligent Operating System
Display Monitor 17 inch industrial LCD control display
Power Supply 220V 50/60Hz
Average Power 400W
Overall Dimensions (Desktop) 1400 x 900 x 900mm
Equipment Weight (Desktop) 210kg
XY Drive Rail Linear guide + THK precision ball screw

Recommended Compact SMT Line with HW-T4

Entry-Level Line

Manual stencil printer + HW-T4 + HW-R306 desktop reflow oven

Small Batch Production Line

Semi-auto stencil printer + HW-T4 + conveyor + HW-R408 reflow oven

Best for: R&D labs, prototyping teams, LED module samples, small batch PCB assembly, startup electronics workshops.
